250 SX (2020) AVGASPORT MEKANISM
SAMTLIGA DELAR
ORIGINALDELAR
EFTERMARKNADSDELAR
1
0019050106S Lagerstatus: 10
hex lobe countersunc screw M5x, Åtgår 4st
20:-
2
54837062000 Lagerstatus: hos lev.
RETAINING PLATE R/S 07
80:-
3
54837063000 Lagerstatus: hos lev.
RETAINING PLATE L/S 07
80:-
4
0770160021 Lagerstatus: 16
O-RING 16,00X2,00 VITON, Åtgår 2st
30:-
5
55437061044 Lagerstatus: hos lev.
CONTR.VALVE 250 LEFT KPL.
420:-
6
55437062044 Lagerstatus: hos lev.
CONTR.VALVE 250 RIGHT KPL.
420:-
10
014580060256 Lagerstatus: hos lev.
CYL. SCREW DIN14580 M 6X25
15:-
11
54637067000 Lagerstatus: 1-3
SPRING SLEEVE
30:-
12
55537066000 Lagerstatus: hos lev.
Overload spring
40:-
13
014580060106 Lagerstatus: hos lev.
Cap head screw M6x10
15:-
14
55537065000 Lagerstatus: hos lev.
Adjusting lever cmpl.
190:-
15
55537080000 Lagerstatus: hos lev.
Post mount cmpl.
330:-
16
55537064044 Lagerstatus: hos lev.
Gear segment right cmpl.
295:-
17
54837064150 Lagerstatus: hos lev.
GEAR SEGMENT L/S 250 07
360:-
18
50437023100 Lagerstatus: 10
exaust flap bushing, Åtgår 2st
60:-
19
0770150151 Lagerstatus: 4-6
O-RING 15,00X1,50 VITON, Åtgår 2st
30:-
20
55537020000 Lagerstatus: hos lev.
Control hatch 250
785:-
21
014580060166 Lagerstatus: 10
SHCS ISO 14580 M6x16
15:-
22
0137060003 Lagerstatus: 4-6
spring washer DIN 137 B - 6
10:-
23
0021060003 Lagerstatus: 12
WASHER DIN9021-A 6,4
10:-
24
54637056100 Lagerstatus: 8
WASHER 6,5X11X2
10:-
25
0014050123 Lagerstatus: 4-6
HH COLLAR SCREW M 5X12 WS=6
20:-
26
0349000050 Lagerstatus: 1-3
WASHER DIN7349-5X15X2
10:-
27
55437058000 Lagerstatus: hos lev.
BEARING SUPPORT
120:-
28
0025050256S Lagerstatus: hos lev.
HH collar screw M5x25 TX30, Åtgår 2st
20:-
29
55537068000 Lagerstatus: hos lev.
Bearing sleeve
75:-
31
55537050444 Lagerstatus: 1-3
Centrifugal governor assy.
1525:-
36
54637098100 Lagerstatus: hos lev.
BALL BEARING 626LLBC3/5K
85:-
40
0014050203 Lagerstatus: 15
HH COLLAR SCREW M 5X20 WS=6, Åtgår 2st
20:-
41
54637070300 Lagerstatus: hos lev.
Closing cover 250-360
305:-
43
54837075000 Lagerstatus: 1-3
SPRING GUIDE 250/300
115:-
43
35-89 Lagerstatus: 4-6
EMX EE Avgasportsnyckel KTM 25... mer info



EMX EE Avgasportsnyckel KTM 25

Dölj ytterligare info
125:-
44
0770021120 Lagerstatus: 1-3
O-RING 12,37X2,62 NBR70
15:-
45
0770240020 Lagerstatus: 4-6
O-RING 24,00X2,00 NBR70
15:-
46
54837069000 Lagerstatus: 1-3
ADJUST. SPRING 2003
30:-
47
54637072300 Lagerstatus: 4-6
AUXILIARY SPRING MID. YELLOW
20:-
48
54637071200 Lagerstatus: hos lev.
SPRING INSERT
100:-
50
47237056100 Lagerstatus: 1-3
angle lever
345:-
51
0988101610 Lagerstatus: 1-3
SHIM WASHER DIN988 10X16X1, Åtgår 2st
10:-
52
0618101410 Lagerstatus: 1-3
needle sleeve HK 1010 10x14x10, Åtgår 2st
50:-
53
55437057200 Lagerstatus: hos lev.
Control lever 250/300
340:-
60
55537095044 Lagerstatus: hos lev.
Linkage cmpl.
200:-
61
50237195055 Lagerstatus: 8
SECURING DIN-71805-S-8, Åtgår 2st
15:-
